- Power Consumption Without Lamp: 45W; With Lamp: 50W
- Height 155mm (6.1")
- Width 510.5mm (20.1")
- Depth 498.5mm (19.63")
- Weight Net >9.5kg (20.94 lbs)
- Auxiliarys (MON, FX, AUX) 2 Pre, 2 Post, 2 Pre/Post switchable
- Channels 6
- CMRR, MIC input, 1 kHz >80dB
- Digital Audio Interface Channels: 4 In / 4 Out; AD/DA Conversion: 24-bit; Sampling Rate: 44.1 / 48 / 88.2 / 96kHz; PC Interface: USB2.0, Female Type B; Peak Display: 6 dB before Clip
- Displays 128 x 64 pixels, OLED
- Effects Type: Dual stereo 24/48-bit multi effects processors; Effects presets: 100 Factory + 20 User, Tap-Delay; Remote control: Footswitch, MIDI;
- Equalization LO Shelving: ±15dB / 60Hz; MID Peaking, mono inputs: ±15dB / 100Hz to 8kHz; MID Peaking, stereo inputs: ±12 dB / 2.4 kHz; HI Shelving: ±15 dB / 12 kHz; Master EQ 11-band (63, 125, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 12kHz): ±10dB / Q = 1.5 to
- Equivalent Input Noise, MIC input, A-weighted, 150 ohms -130dBu
- Filter LO-CUT, mono inputs: f=80Hz, 18dB/oct; VOICE FILTER, mono inputs: switchable; FEEDBACK FILTER, MON ½: 70Hz to 7kHz, Notch, -9dB
- Input Impedances MIC: 2㏀; Insert Return: > 3.3㏀; 2Track Return & CD In: 10㏀; All other inputs: > 15㏀
- Input Sensitivity MIC: -74dBu (155μV); LINE (Mono): -54dBu (1.55mV); LINE (Stereo): -34dBu (15.5mV); CD (Stereo): -34dBu (15.5mV)
- LINE/CD/USB GAIN (Stereo) -10…+20dB
- Maximum SPL MIC Inputs: +21dBu; Mono Line inputs: +41dBu; Stereo Line inputs: +30dBu; All other inputs: +22dBu; All other outputs: +22dBudB
- MIC GAIN (Mono) 0…+60dB
- MIC GAIN (Stereo) +10 to +60dB
- MIDI Interface 5-pin DIN connector, In / Out
- Noise, Channel inputs to Master A L/R outputs, A-weighted Master fader down: -97dBu; Master fader 0dB, Channel fader down: -91dBu; Master fader 0dB, Channel fader 0dB, Channel gain unity: -83dBu
- Operating Temperature Range +5 °C…+40 °C (40 °F…105 °F)
- Output Impedances Phones: 47Ω; All other outputs: 75Ω
- Phantom Power 48VDC
- >Protection Mixer Outputs (Relay controlled): MON 1, MON 2, MASTER A; Switching Mode Power Supply (μC controlled): Mains Over/Undervoltage, High Temperature
- Safety Class I
- Shipping Weight 12.5kg (27.56 lbs)
- Total Harmonic Distortion
Product specifications may vary according to country or project needs when ordering
Thông số kỹ thuật sản phẩm có thể thay đổi tùy theo nhu cầu của quốc gia hoặc dự án khi đặt hàng
