Power Source | AC mains (supplied AC adapter must be used) |
---|---|
Power Consumption | 25 W or less |
Current Consumption | 1.6 A (12 - 15 V DC) |
Frequency Range | VHF/UHF |
Antenna Input | 2 inputs per distribution channel (front × 1, rear × 1), 75 Ω, BNC (phantom powering for antenna) |
Antenna Output | 4 outputs per distribution channel, 75 Ω, BNC |
DC Power Supply | 4 output (each output: 12 V DC/250 mA) (Output voltage of this unit depends on that of AC adapters.) |
Indicator | Power lamp |
Operating Temperature | -10℃ to +50℃ |
Operating Humidity | 30 % to 85 %RH (no condensation) |
Finish | Panel: Aluminium, black, paint Case: Steel, black, paint |
Dimensions | 420 (W) × 44 (H) × 214 (D) mm |
Weight | 2 kg |
Accessory | AC adapter*1 x 1, Power cord (2m)*1 x 1, DC cable x 4, Rubber foot x 4 |
Option | Rack mounting bracket: MB-15B |
Product specifications may vary according to country or project needs when ordering
