Micro PZM11 LL WR

The PZM11 LL WR is a professional weather-resistant boundary layer microphone designed for fast-food restaurants, outdoor intercoms, toll booths, SOS telephones, theme-park security and the like. A plastic membrane inside the microphone protects the mic capsule from water damage. The PZM11 LL WR will work during and after rainfall. If water freezes on the membrane, the mic’s frequency response will change but will return to normal when the ice melts and the membrane dries.

The PZM11 LL WR is powered by 12V - 24V DC, provides line-level output and can be plugged directly into a VCR line input without the need for a costly mic preamp.

Thông số kỹ thuật

General Specifications

• Audio frequency bandwidth : 80 - 10000 Hz
• Equivalent noise level : 26 dB-A
• Sensitivity : 5 mV/Pa
• Signal to Noise : 68 dB-A

Dimensions

• Length : 70 mm
• Width : 115 mm
• Height : 44 mm
• Net Weight : 71 g

Design

• Finish : silver gray

Audio Output

• Type : screw material
• Powering Interface
• Voltage : 12 to 24 V

Application

• Retail : Yes

Device

• Boundary Layer Microphone : Yes
