Digital wireless receiver combines professional features with streamlined set-up and operation. Features include Automatic Channel scan, Networked Channel Scan, digital predictive switching, and AES 256 encryption for security.

  • Automatic Channel Scan quickly finds clear frequencies; Networked Channel Scan then shares open frequencies between multiple receivers over Ethernet, with one touch syncing
  • Digital Predictive Switching Diversity ensures a stable RF connection
  • Highly efficient RF spectrum usage – up to 22 transmitters per 8 MHz channel
  • Secure AES 256 bit encryption of all wireless transmissions
  • Shure Wireless Workbench® software allows remote control from PC or Mac
  • ShurePlus™ Channels mobile app allows remote control from iOS devices
  • Half rack format with detachable ½ wave antennas
  • Up to 60 dB of adjustable audio gain
  • Up to 72 MHz tuning bandwidth (region dependent)
  • More than 60 pre set compatible channels per frequency band (region dependent)
  • High contrast LCD menu and controls with lockout feature, plus Audio and RF LED meters with peak indicator
  • Mic / line switchable XLR output, and 6.3 mm instrument output
  • Durable aluminium construction with brushed finish

Thông số kỹ thuật

RF Carrier Frequency RangeH50: 534 to 598 MHz
Working Range328' (100 m)
RFTuning Step Size: 25 kHz, varies by region
Image RejectionGreater than 70 dB, typical
RF Sensitivity−97 dBm at 10-5 BER
LatencyLess than 2.9 ms
Audio Frequency Response20 Hz - 20 kHz (±1 dB)
Audio Dynamic RangeSystem Gain @ +10: Greater than 120 dB, A-weighted, typical
Total Harmonic Distortion (THD)−12 dBFS Input, System Gain @ +10: Less than 0.1%
PolaritySystem Audio: Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (1/4-inch) output
Operating Temperature Range0 to 122°F (-18 to 50°C)
Storage Temperature Range-20 to 165°F (-29 to 74°C)
HousingSteel
RF InputSpurious Rejection: Greater than 80 dB, typical
Connector Type: BNC
Impedance: 50 ohms
Power Requirement12 VDC @ 0.4 A, supplied by external power supply (tip positive)
Dimensions (H x W x D)1.63 x 7.75 x 5.94" (41 x 197 x 151 mm)
Weight1.71 lb (777 g)



Product specifications may vary according to country or project needs when ordering
Thông số kỹ thuật sản phẩm có thể thay đổi tùy theo nhu cầu của quốc gia hoặc dự án khi đặt hàng
