| Frequency range | 1G8: 1785 - 1800 MHz A: 516 - 558 MHz A1: 470 - 516 MHz AS: 520 - 558 MHz B: 626 - 668 MHz C: 734 - 776 MHz D: 780 - 822 MHz E: 823 - 865 MHz G: 566 - 608 MHz GB: 606 - 648 MHz |
| Dimensions | Approx. 190 x 212 x 43 mm |
| Compander | Sennheiser HDX |
| THD, total harmonic distortion | ≤ 0.9 % |
| Weight | Approx. 980 g |
| Audio output | 6.3 mm jack socket (unbalanced): +12 dBu XLR socket (balanced): +18 dBu |
| Signal-to-noise ratio | ≥ 110 Dba |
| Switching bandwidth | up to 42 MHz |
| Peak deviation | ±48 kHz |
| Nominal deviation | ±24 kHz |
| Modulation | Wideband FM |
| Power supply | 12 V DC |
| Antenna connector | 2 BNC sockets |
| Current consumption | 300 mA |
| Adjacent channel rejection | Typically ≥ 65 dB |
