Micro CGN341 E

The CGN341 E DAM+ set is a Discreet Acoustics Modular Plus tabletop microphone set that provides the components needed to handle a wide range of applications with the flexibility to cover a variety of situations. It features the CK41 Reference Cardioid Condenser Microphone Capsule, the W40 M windscreen, the GN30 M Reference DAM+ series gooseneck module and the PAE M Reference Phantom Power Module. The CK41 offers a wide cardioid polar patter and a speech optimized studio quality frequency response. It’s especially suited for inexperienced or very vivacious speakers and applications where more than one person uses the microphone in turn.

The whole set is extremely slim, but still rugged and features an LED ring that indicates whether the phantom power is on or off. The PAE M phantom power module provides a gold-plated XLR connector and a 250Hz bass roll off to minimize structure-borne noise.

The included windscreen uses a double layer wire mesh, eliminating literally all wind and pop noise issues.

Thông số kỹ thuật

General Specifications

• Audio frequency bandwidth : 50 - 20000 Hz
• Equivalent noise level : 30 dB-A
• Sensitivity : 5 mV/Pa
• Signal to Noise : 64 dB-A
• Polar Pattern : Cardioid

Dimensions

• Length : 380 mm
• Height : 380 mm
• Diameter : 6 - 20 mm
• Net Weight : 160 g

Design

• Body : metal
• Finish : matte black

Audio Output

• Type : Balanced XLR
• Gender : Male
• Contacts : 3-pin

Powering Interface

• Voltage : 9 to 52 V
• Current : 3 mA

Application

• Conferencing : Yes
• Presentation : Yes

Device

• Gooseneck Microphone : Yes
